TOBO GROUP Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade

Name: TOBO GROUP Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade
Brand: TOBO
Price: 1 USD

Quality TOBO GROUP Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade for sale

Brand Name : TOBO

Model Number : ASTM A554, A312, A249, A269 And A270,A688

Certification : LR,BV,SGS,BIS,DNV,CRN,ABS,TUV，

Place of Origin : CHINA

MOQ : 1PCS

Price : 1USD

Payment Terms : TT/LC

Supply Ability : 300000T/Year

Delivery Time : 0-30days

Packaging Details : WOODCASE or PLATE

Material Grade : 201,202,301,304,316,430,304L,316L

Outer Diameter : 9.53mm-101.6mm

Standard : ASTM A554, A312, A249, A269 And A270,A688

Type : Stainless Steel Welded Pipe / Tube

Contact Now

Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade

Detailed Product Description

Material Grade:	201,202,301,304,316,430,304L,316L	Outer Diameter:	9.53mm-101.6mm
Standard:	ASTM A554, A312, A249, A269 And A270,A688	Surface Finish:	180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish) 400G, 600G Mirror Finish
Type:	Stainless Steel Welded Pipe / Tube	Wall Thickness:	0.3mm - 3.0mm

Thin Wall TIG Welded Stainless Steel Pipe For Handrail 201 304 Grade

Quick Detail:

The welded stainless steel pipe is made from stainless steel by electric welding or sheet metal strips by means of forming and welding. Electrically welded tube is made of thermally without subsequent processing and hot-reducing.

Name	Stainless steel welded pipe/ tube
Standard	ASTM A554, A312, A249, A269 and A270,A688
Material Grade	201,202,301,304,316,430,304L,316L
Size Range	20x10mm--100x50mm,10x10mm-100x100mm, 9.53-101.6mm, we can also accept sizes above 101.6mm
Thickness	0.3mm - 3.0mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/- 0.2mm
	b) Thickness: +/- 0.02mm
	c) Length: +/- 5mm
Surface	180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish) 400G, 600G Mirror finish
Application	Window,Door,Handrail,Curtain rail,Towel rail,Flagpole,Lamp pole,Sanitary Instrument,Billboard,Decoration,Upholstery, Construction,Accessory,Airport,Bus Stop
Test	Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT
Chemical Composition of Material	Composition Material	201	202	304	316L	430
	C	≤0.15	≤0.15	≤0.08	≤0.35	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	13-15	14-17	18-20	16-18	16-18
	Ni	0.7-1.1	3.5-4.5	8-10.5	10-14
	Mo				2.0-3.0
Mechanical Property	Material Item		201	202	304	316
	Tensile Strength		≥535	≥520	≥520	≥520
	Yield Strength		≥245	≥205	≥205	≥205
	Extension		≥30%	≥30%	≥35%	≥35%
	Hardness (HV)		<105	<100	<90	<90

ADVANTAGE:

1, Direct material sourcing from Bao Steel, ZPSS, TISCO.
2, More than 5 processing mills to produce the welded titanium tube for us. And also we own a steel tube mill.
3, Strong business cooperation with Bao Steel and Shanghai Minmetals.
4, More than usd$50,000,000 annual turnover.

We are professional manufacturer of stainless steel products, including stainless steel decorative pipes,industrial stainless welded pipes, special-shaped pipes, stainless steel sheet and etc.
